5300-M1 Series Double Row Angular Contact Ball Bearings
Double Row Angular Contact Ball Bearings
« 6
Item # |
Bore d |
Outside Diameter D1 |
Width B |
Grease Speed Rating n1 |
Basic Dynamic Radial Load Rating C |
Basic Static Radial Load Rating Co |
|---|---|---|---|---|---|---|
| 5315-M1ZZ | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1G | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1FG | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1FFG | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1FZG | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1ZG | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
| 5315-M1ZZG | Bore d N/A 75.000 mm | Outside Diameter D1 N/A 160.0000 mm | Width B N/A 71.40 mm | Grease Speed Rating n1 N/A 2600 rpm | Basic Dynamic Radial Load Rating C N/A 187000 N | Basic Static Radial Load Rating Co N/A 208000 N |
« 6
